INS-LW SERIES - PRODUCT SPECIFICATIONS & LITERATURE

The INS-LW (Silver) Light Washdown Series is the new IP65 Lightweight, Low Profile, Class II Low Forward Voltage, Low energy consuming LED in the LEI Industrial Line. The INS-LW Series provides an economical, reliable LED alternative to 250-400 watt metal halide fixtures. While other UFO designs are mainly Class I, this provides a safer, low forward voltage alternative, that is quality made and non-ferrous. In addition, the INS-LW Series provides dual drivers standard in the 20,000 to 24,000 lumen units, versus most, that utilize only one driver. The INS-LW Series light engine provides you with a minimum punch of 135 Lumens per watt, as well as a “Plug and Play” concept out of the box, with a 3 ft, 18/3 pigtail. The Hook Loop is included and installed with the unit. The INS-LW Series is the IP65 solution for your light wash-down applications.

  • PDF FILES

    SPECIFICATIONS

  • PHOTOMETRIC FILES

    INS-LW-12L-5K8-U-F-XX
    INS-LW-16L-5K8-U-F-XX
    INS-LW-20L-5K8-U-F-XX
    INS-LW-24L-5K8-U-F-XX

  • IES FILES

    INS-LW-12L-5K8-U-F-XX
    INS-LW-16L-5K8-U-F-XX
    INS-LW-20L-5K8-U-F-XX
    INS-LW-24L-5K8-U-F-XX

PRODUCT FEATURES

Light Wash-Down Series IP65
Lightweight, Low-Profile, Class II Low Forward Voltage
Aluminum Housing and Reflector for Superior Thermal Management
Clear Acrylic Lens in Dome Design for improved Light Distribution
Economical and Reliable
Non-Ferrous
Industrial Line
Dual Drivers Standard in the 20,000 and 24,000 lumen units
Light Engine Provides Minimum Punch of 135 Lumens per Watt
Plug and Play Design
Aluminum Main Housing
Heat Sinking Aluminum Reflector for Superior Thermal Management
Optional 0-10V Dimming and Motion Sensor Configurations Available

FIXTURE CONFIGURATOR

Use part number configurator to build your model

Consult factory for all available options and configurations.
Not all configurations of this fixture may be DLC qualified. Please consult the DLC Qualified Products list @ www.designlights.org to see if the version in which you are interested, is listed.

Series
INS3-LW = Industrial Series (3 Year LW)
INS5-LW = Industrial Series (5 Year LW)
 Lumens
12L = 12,000
16L = 16,000
20L = 20,000
24L = 24,000
 5K 70CRI and 5K 80CRI
5K8 = 5,000K, 80CRI (Standard)
5K7 = 5,000, 70 CRI
 Voltage
U = 120V-277V
 Lens
C = Clear Acrylic - Domed
F = Low Glare - Domed
 Optional features
MOS = Microwave Occupancy Sensor
DMS = Dimming Occupancy Sensor
SCL = Safety Cable Loop
 Optional Power End
P3 = 3' Lead - 18/3 black
P4 = 4' Lead - 18/3 black pigtail
PX = X' Lead - 18/3 black pigtail (Specify Length)
